What are the classification and main structures of wire drawing machine?
LT type wet wire drawing machine
The diameter range of the finished wire drawing is between 0.1-1.2mm, and the working characteristics are sliding wire drawing and multi-pass drawing;
LW type pulley wire drawing machine
The diameter range of the finished wire drawing is between 0.5-4.5mm, and the working characteristics are non-slip wire drawing and twisting;
LS type double drum wire drawing machine
The diameter range of the finished wire drawing is between 0.4-3.5mm, and the working characteristics are non-slip wire drawing and no twisting;
LH type looper wire drawing machine
The diameter range of the finished wire drawing is between 0.5-6.0mm, and the working characteristics are no slipping and no twisting;
LZ type straight line wire drawing machine
The diameter range of the finished wire drawing is between 0.5-7.0mm, and the working characteristics are no slipping and no twisting;
LD type single-pass wire drawing machine
The diameter range of the finished drawn wire is no more than 22mm, and the working characteristics are 1-2 passes of drawing;
Horizontal wire drawing machine
The diameter range of the finished wire drawing is 6.5-24mm, the working characteristics are non-slip wire drawing, and the diameter of the drawn wire is large;
Inverted wire drawing machine
The diameter range of the finished wire drawn wire is no more than 30mm. The working characteristics are high degree of automation, the ability to draw and take up the wire at the same time, the take-up reel can be up to 2, the wire unloading is convenient and reliable, easy to operate, high production efficiency, safe and reliable.
